Can You Use Urethane Casting for Overmolding and Insert Molding
2026-06-30
For product developers and manufacturing engineers, Urethane Casting is already a well-known solution for low-volume production and functional prototyping. However, a frequent question arises when project timelines tighten and budgets are constrained: can this versatile process handle overmolding and insert molding? The short answer is yes—but with critical nuances. At Moldburger, we have executed hundreds of overmolded and insert-molded parts using Urethane Casting, and this article breaks down exactly how, when, and why it works, along with the limitations you must respect.
What Are Overmolding and Insert Molding in the Context of Urethane Casting?
Before evaluating feasibility, it is essential to define both terms clearly within the silicone mold environment.
| Process | Definition | Typical Application |
|---|---|---|
| Overmolding | Casting a second urethane layer over a first cured urethane substrate (or a different elastomer) to create a soft-touch grip, seal, or dual-durometer component. | Hand tools, medical device handles, gaskets with rigid cores. |
| Insert Molding | Placing a pre-manufactured insert (metal, plastic, ceramic, or PCB) into the mold cavity before pouring liquid urethane, so the cured resin encapsulates or secures the insert. | Threaded inserts, sensor housings, electrical connectors, weight-added components. |
Both techniques are entirely possible with Urethane Casting, provided you adjust your mold design, material selection, and curing parameters.
Why Urethane Casting Works for Overmolding and Insert Molding
Urethane Casting offers three distinct advantages that make it superior to injection molding for these applications in low-to-medium volumes:
-
Room-temperature or low-heat curing – This protects heat-sensitive inserts (e.g., electronics, thin-walled plastics) from thermal degradation, whereas injection molding typically requires 200–300°C melt temperatures.
-
Excellent chemical adhesion – Polyurethane chemistry readily bonds to itself (for overmolding) and to many engineering plastics (PC, ABS, Nylon) and metals when properly primed.
-
Flexible durometer range – You can cast a Shore A 30 soft layer over a Shore D 80 rigid core in the same silicone tool, eliminating secondary assembly steps.
At Moldburger, we routinely produce overmolded surgical handles and insert-molded brass nuts using vacuum-assisted Urethane Casting, achieving pull-out strengths exceeding 500 N on M4 inserts.
Critical Design Rules and Limitations
While feasible, Urethane Casting imposes stricter constraints than injection molding. The table below summarizes the key parameters you must control:
| Parameter | Overmolding | Insert Molding |
|---|---|---|
| Minimum wall thickness over insert | 1.5 mm (to avoid voiding) | 2.0 mm (for metal inserts) |
| Maximum insert temperature | 60°C (during exothermic peak) | 60°C (same limitation) |
| Chemical primer required | Yes, for dissimilar materials | Yes, for metals and untreated plastics |
| Shrinkage mismatch tolerance | ≤ 0.5% difference between layers | Inserts must be undercut or knurled |
| Cycle time (per part) | 4–8 hours (cure + post-cure) | 3–6 hours (depends on insert mass) |
A common pitfall is thermal expansion: metal inserts expand when the liquid urethane exotherms (reaches 70–90°C internally). After cooling, the metal shrinks less than the urethane, potentially causing micro-cracks. Moldburger mitigates this by pre-heating inserts to 50°C and using low-exotherm urethane grades.
Step-by-Step Workflow for Insert Molding with Urethane Casting
-
Insert preparation – Degrease, grit-blast, and apply a silane-based adhesion promoter.
-
Fixture positioning – Place the insert into the silicone mold using removable pins or magnetic holders.
-
Vacuum degassing – Pour the urethane resin under vacuum (28 inHg) to eliminate air trapped around the insert.
-
Pressure curing – Cure at 40°C for 2 hours under 4–5 bar pressure to collapse any residual bubbles.
-
Post-curing – Oven-bake at 70°C for 4 hours to achieve final mechanical properties.
For overmolding, the sequence is similar, but the first substrate must be fully post-cured, lightly abraded, and primed before the second pour. Without these steps, delamination occurs within days.
Urethane Casting – FAQ (Frequently Asked Questions)
Q1: Can Urethane Casting bond to untreated aluminum inserts without primer?
A1: No. Unprimed aluminum forms a weak oxide layer that inhibits urethane adhesion. Pull-out tests show a 70–80% reduction in bond strength without primer. Moldburger uses a proprietary isocyanate-based primer applied as a 5-micron film, then air-dried for 15 minutes before casting. With priming, aluminum inserts achieve cohesive failure (the urethane tears before the bond breaks) at ≥ 600 N for a 6 mm diameter knurled pin.
Q2: How many overmolding cycles can a single silicone mold withstand before the soft layer distorts?
A2: A high-temperature tin-cured silicone mold (Shore A 40) typically endures 15–20 overmolding cycles before the cavity walls soften from repeated exothermic heat. Platinum-cured silicones extend this to 30–35 cycles. Moldburger recommends using platinum-cured tools with integral cooling channels for runs exceeding 25 pieces. After 30 cycles, we re-measure the cavity dimensions; distortion often exceeds 0.15 mm, which fails tolerance for class-A surfaces.
Q3: Is it possible to overmold a Shore A 70 urethane layer over a Shore D 60 rigid urethane core in the same casting session?
A3: Yes, but not simultaneously. The rigid core must cure for at least 6 hours at 60°C, then cool to 25°C, before the soft layer is poured. If poured too early, the residual exotherm from the core will accelerate the soft layer's gel time, reducing pot life from 12 minutes to under 4 minutes, causing poor flow and trapped air. Moldburger schedules overmolding as a two-day process: day 1 for cores, day 2 for soft layers, with an intermediate sanding step (320-grit) to ensure mechanical interlocking.
When to Avoid Urethane Casting for These Applications
Despite its advantages, Urethane Casting is not suitable for:
-
Inserts with sharp corners or < 1 mm edge distance (stress risers cause cracking).
-
High-volume production (> 500 units) – injection molding becomes more cost-effective.
-
Inserts requiring > 150°C service temperature – urethane degrades above 120°C continuous.
For such cases, Moldburger advises transitioning to insert injection molding or transfer molding.
Conclusion and Contact
Urethane Casting is not only viable but often optimal for overmolding and insert molding when volumes range from 10 to 250 pieces, part sizes are under 600 mm, and inserts are heat-sensitive. The process demands rigorous primer application, precise insert fixturing, and thermal management—but delivers functional, durable assemblies that rival injection-molded counterparts.
