A maintenance engineer at a semiconductor fab examines a graphite susceptor that has been in service for eight months in a chlorine-based etch process. The surface is pitted and flaking. The particles that have detached from the surface are contaminating the wafer environment. The engineer compares this component with a similar component from another supplier that has been in service for three years with no visible degradation. The difference is the Silicon Carbide Coating. The first component has a thin, porous coating with visible defects. The second component has a dense, high-purity coating with no visible defects. The coating is the barrier that separates the reactive process gas from the graphite substrate. If the coating is not dense and continuous, the gas penetrates to the substrate and attacks it. This guide explains how silicon carbide coating protects components exposed to reactive process gases.
Reactive process gases such as chlorine (Cl₂), hydrogen chloride (HCl), fluorine (F₂), and nitrogen trifluoride (NF₃) are used in semiconductor etching, chamber cleaning, and surface treatment. These gases are highly reactive because they have unpaired electrons or because they form strong bonds with the materials they contact. Graphite is attacked by these gases at high temperatures. The gas reacts with the carbon to form volatile compounds such as carbon tetrachloride (CCl₄) or carbon tetrafluoride (CF₄). The graphite surface erodes, and particles are released. Metals such as stainless steel and aluminum are also attacked. They form metal chlorides or fluorides that are volatile or that flake off. The table below shows the reactivity of common materials with reactive process gases.
| Material | Chlorine resistance | Fluorine resistance | Maximum temperature | Typical failure mode |
| Graphite | Poor | Poor | 500°C (in Cl₂) | Erosion, particle release |
| Stainless steel 316 | Moderate | Poor | 300°C (in Cl₂) | Pitting, chloride stress corrosion |
| Aluminum | Poor | Poor | 150°C | Rapid corrosion |
| Silicon carbide coating | Excellent | Excellent | 1,200°C | None (if coating is dense) |
| Silicon nitride | Good | Moderate | 1,000°C | Gradual oxidation |
In our factory, we manufacture Silicon Carbide Coating for graphite components used in semiconductor and chemical processing equipment. The coating is applied by chemical vapor deposition (CVD) at high temperature. The CVD process produces a dense, high-purity coating that is chemically inert to most process gases. WuYi TianYao New Material Tech.Co.,Ltd. has been developing CVD silicon carbide coatings for over 10 years.
The Silicon Carbide Coating protects the substrate by forming a barrier that the reactive gas cannot penetrate. The barrier works if the coating is dense and continuous. Density is measured by the absence of porosity and micro-cracks. Continuity is measured by the absence of pinholes and thin spots. The CVD process produces a coating with a density of 3.20 to 3.21 g/cm³, which is 99.5 percent of the theoretical density of silicon carbide. The table below shows the relationship between coating density and gas penetration.
| Coating density (g/cm³) | Porosity (%) | Gas penetration | Expected lifetime in Cl₂ at 800°C |
| 3.00 | 6.5 | High (open porosity) | < 3 months |
| 3.10 | 3.5 | Moderate | 6 – 12 months |
| 3.18 | 1.0 | Low | 2 – 3 years |
| 3.20 – 3.21 | < 0.5 | Very low (sealed) | > 3 years |
Corrosion engineer's note: The density of the coating is the most important factor in determining its protective lifetime. A coating with 3 percent porosity will allow gas to penetrate to the substrate and cause failure within a year. A coating with less than 0.5 percent porosity will protect the substrate for three years or more. In our factory, we measure the density of every coating batch using the Archimedes method. We also perform a helium leak test on sample components to verify that the coating is continuous and free of pinholes.
The thickness of the Silicon Carbide Coating affects both the protection and the mechanical stress. A thicker coating provides a longer diffusion path for the gas, which extends the protection time. However, a thicker coating also has higher residual stress because the coating and the substrate have different thermal expansion coefficients. If the stress exceeds the bond strength, the coating can crack or delaminate. The table below shows the relationship between coating thickness, protection time, and stress.
| Coating thickness (μm) | Protection time (relative) | Residual stress (MPa) | Delamination risk |
| 20 – 30 | Baseline | 50 – 80 | Low |
| 50 – 70 | 2 – 3x baseline | 100 – 150 | Low |
| 80 – 100 | 3 – 5x baseline | 150 – 200 | Moderate |
| 120 – 150 | 5 – 7x baseline | 200 – 280 | High (requires stress relief) |
In our factory, we recommend a coating thickness of 50 to 100 μm for most components exposed to reactive process gases. This thickness provides a good balance between protection and stress. For components with complex geometry or sharp edges, we recommend a thinner coating (30 to 50 μm) to reduce the stress concentration. We also use a graded coating process that gradually transitions from the substrate to the pure silicon carbide, which reduces the residual stress and improves the bond strength. VETEK provides coating thickness recommendations for each application.
The Silicon Carbide Coating should be inspected before installation and at regular intervals during service. The inspection should check for four things: coating thickness, density, adhesion, and surface defects. The thickness is measured with an eddy current gauge or by cross-section microscopy. The density is measured by the Archimedes method or by helium leak testing. The adhesion is measured by a scratch test or a pull-off test. The surface defects are checked visually and with a dye penetrant. The table below shows the inspection criteria for coated components.
| Inspection item | Acceptance criteria | Method |
| Coating thickness | ±10% of specified value | Eddy current gauge |
| Density | > 3.18 g/cm³ | Archimedes method |
| Adhesion | > 50 MPa | Pull-off test |
| Surface defects | No visible cracks, pinholes, or delamination | Visual and dye penetrant |
| Helium leak rate | < 1 x 10⁻⁶ mbar·L/s | Helium leak detector |
In our factory, we perform all of these inspections on every coated component before shipment. We also provide a certificate of analysis that includes the thickness, density, and adhesion data. WuYi TianYao New Material Tech.Co.,Ltd. recommends that customers inspect the coating at the start of each maintenance cycle and after any event that could damage the coating, such as a chamber clean or a mechanical impact.
Silicon Carbide Coating protects components exposed to reactive process gases by forming a dense, chemically inert barrier that blocks gas penetration. The density of the coating is the most important factor in determining its protective lifetime. A coating with a density above 3.18 g/cm³ and a thickness of 50 to 100 μm provides the best balance of protection and stress. The coating should be inspected for thickness, density, adhesion, and surface defects before installation and at regular intervals during service. WuYi TianYao New Material Tech.Co.,Ltd. has been developing CVD silicon carbide coatings for over 10 years and provides full inspection and certification support for our customers.
