How Material Thickness Affects Sheet Metal Fabrication Parts?

A customer sends a drawing for a bracket. The only change from the previous order is the material thickness—from 2 mm to 3 mm. The price comes back 60 percent higher. The customer asks why. The answer is not arbitrary. Material thickness affects every step of the sheet metal fabrication parts process: the cutting method, the bending force, the tooling selection, the weld preparation, and the finishing time. A 1 mm increase in thickness can push a part from the light-gauge category into the heavy-gauge category, which changes the entire manufacturing approach. This guide explains how thickness drives those decisions so that designers and buyers can make informed choices.

1. How Does Thickness Determine the Cutting Method for Sheet Metal Fabrication Parts?

The first operation in any sheet metal fabrication parts project is cutting the flat pattern. The thickness determines which cutting technology is used. For thin materials—0.5 mm to 3 mm—fiber laser cutting is the standard. It provides a narrow kerf, a smooth edge, and high speed. For medium thickness—3 mm to 6 mm—laser cutting is still used, but the cutting speed drops significantly, and the edge quality may require secondary finishing. For thick materials—6 mm to 25 mm—plasma cutting or waterjet cutting becomes more economical. Plasma cutting is faster than laser for thick plate, but it leaves a rougher edge. Waterjet cutting provides a smooth edge with no heat-affected zone, but it is slower and more expensive. The table below shows the typical cutting method and speed for different thicknesses.

In our factory, we operate fiber laser cutters for materials up to 6 mm and plasma cutters for materials up to 25 mm. We select the cutting method based on the thickness, the required edge quality, and the quantity. For a part that will be visible after assembly, we recommend laser cutting even for thicker materials because the edge quality is better. For a structural part that will be painted, plasma cutting is sufficient and more economical.

2. Why Does Bending Become More Difficult as Thickness Increases?

Bending is the operation that forms the flat pattern into a 3D shape. The required bending force increases with the square of the thickness. This means that doubling the thickness requires four times the bending force. A press brake that can bend 2 mm steel may not be able to bend 4 mm steel at the same length. The tooling also changes. Thin materials can be bent with a sharp punch and a V-die with a small opening. Thick materials require a larger V-die opening to avoid cracking. The minimum bend radius also increases with thickness. For cold-rolled steel, the minimum bend radius is approximately equal to the thickness. For stainless steel, it is 1.5 times the thickness. The table below shows the relationship between thickness, V-die opening, and minimum bend radius.

Cangzhou Shengsen Metal Products Co., Ltd. operates press brakes with capacities from 40 tons to 400 tons. Our factory can bend materials up to 12 mm thick and 6 meters long. We use a CNC backgauge and a laser angle measurement system to ensure consistent bend angles across the batch.

3. How Does Thickness Affect Tolerances and Fit-Up in Sheet Metal Fabrication Parts?

Thickness affects the achievable tolerances in two ways. First, the dimensional tolerance of the material itself. Hot-rolled steel plate has a thickness tolerance of ±0.5 mm or more, depending on the mill. Cold-rolled steel sheet has a tighter tolerance of ±0.05 mm. If the design requires a tight fit between two parts, the thickness variation must be considered. Second, the thickness affects the thermal distortion during welding. Thick materials require more heat input, which causes more distortion. This can affect the alignment of the assembly. The table below shows the typical thickness tolerances for different materials.

In our factory, we inspect the incoming material thickness with a micrometer before releasing it to production. If the thickness is outside the specification, we reject the batch. This prevents tolerance problems from propagating through the fabrication process.

4. What Is the Cost Impact of Increasing Thickness in Sheet Metal Fabrication Parts?

The cost impact of increasing thickness is not linear. It is the sum of three factors: material cost, processing cost, and finishing cost. Material cost increases proportionally with thickness. Processing cost increases faster than proportionally because of the higher cutting time, higher bending force, and slower welding. Finishing cost also increases because thicker parts require more surface preparation and longer paint curing. The table below shows the relative cost index for a typical bracket at different thicknesses.

Summary for Designers and Buyers

Material thickness is not just a dimension on a drawing. It determines the cutting method, the bending force, the tooling, the tolerances, and the cost of sheet metal fabrication parts. A small increase in thickness can push a part into a different manufacturing category, which changes the lead time and the price. Designers should consider whether a thinner material with a rib or a flange can achieve the same strength at a lower cost. Buyers should understand that the price difference between thicknesses is not arbitrary—it reflects the actual processing requirements. Cangzhou Shengsen Metal Products Co., Ltd. has been manufacturing sheet metal fabrication parts for over 15 years and provides design for manufacturability feedback to our customers.

Cangzhou Shengsen Metal Products Co., Ltd. manufactures sheet metal fabrication parts in a range of materials and thicknesses. We provide DFM feedback, material certificates, and full dimensional inspection reports.
